Waterproof Plug Socket Malaysia
PRODUCT OVERVIEW
The 16A Industrial Waterproof Socket and Plug Set from Blue Box Sdn Bhd is a heavy-duty 3-pin connector for 220-250V supply, rated IP44 and built for sites, workshops, and outdoor setups where a standard household plug is not tough enough. Each set contains one industrial waterproof socket and one matching plug in a blue and white shell, and each piece measures about 125 x 50 x 50mm (4.9 x 2 x 2 inches). It is supplied to contractors, workshops, and event teams across Malaysia.
The contacts are made from 5.00mm brass columns, and brass is a common choice for electrical contacts because it conducts well and resists corrosion better than plain steel. A good, firm contact helps limit heat build-up at the connection, which matters at a full 16A load. The shell is made from high-strength, flame-retardant engineering material, so the housing resists knocks on site and is designed to resist spreading a flame if a fault occurs.
The IP44 rating is worth reading carefully. The first digit (4) means the connector is protected against solid objects larger than 1mm, and the second digit (4) means it is protected against water splashing from any direction. That makes the set suitable for damp, dusty, or rain-exposed locations, but it is not designed for submersion, pressure washing, or being left in a puddle. Treat it as splash-proof, not fully waterproof.
Electrical safety is a core workplace concern, and DOSH Malaysia provides guidance on keeping electrical work safe. In Malaysia, electrical equipment such as plugs and socket-outlets is overseen by Suruhanjaya Tenaga (Energy Commission), so buyers and sellers should confirm the approval status of any plug and socket before use. No certification is claimed on this page, and installation should always be done by a competent person.
Supplied as a matched pair, the socket and plug fit together so you do not need to source them separately, which helps avoid mismatched parts. The compact size makes the set easy to fit into extension leads, temporary power boards, and equipment connections, while the blue colour is a familiar industrial cue that helps crews spot a single-phase 220-250V connection quickly.
Blue Box Sdn Bhd supplies this set as part of its wider Warehouse Operational Supplies range, alongside cable covers and other site supplies, so teams across Petaling Jaya, Shah Alam, Klang, and Selangor can source power connections and cable protection together. Visit www.blue-box.asia to view related products or request a bulk quotation.
Whether you are setting up temporary site power, wiring a workshop, or running power for an outdoor event, the 16A Industrial Waterproof Socket and Plug Set gives you a tough, matched, splash-protected connection.
Product Specifications Table
| Specification | Detail |
| Product Name | 16A Industrial Waterproof Socket and Plug Set (3 Pin, IP44) |
| Brand | BBSB |
| Model No. | P03-00034 |
| Type | Industrial waterproof socket + plug |
| Rated Current | 16A |
| Voltage | 220–250V power supply |
| Number of Conductive Cores / Holes | 3 (3 pin) |
| Protection Level | IP44 (splash-protected; not for submersion or jets) |
| Core Material | Brass (5.00mm large brass column) |
| Shell Material | High-strength flame-retardant engineering material |
| Colour | Blue + white |
| Size | About 125 x 50 x 50mm / 4.9 x 2 x 2 inches (assumed per piece) |
| Package Contents | 1 x industrial waterproof socket, 1 x industrial waterproof plug |
| Item Weight | 0.2–0.4 kg per set (1 socket + 1 plug) |
| Est. Packed Box Size (Courier) | Approx. 15cm (L) x 12cm (W) x 7cm (H) — estimated, based on two 125 x 50 x 50mm pieces side by side plus packing allowance |
| Typical Application | Site and temporary power, workshops, outdoor and event power connections |
| Certification | None stated; confirm applicable approval status before sale |
| Country of Supply | Malaysia (Blue Box Sdn Bhd, Selangor) |
7 PRO Tips
- Tip 1: Have the set wired by a competent, qualified person, and match the cable size to the 16A rating so the cable does not overheat.
- Tip 2: Never exceed 16A or the 220-250V supply range; if the load is close to the limit, use a higher-rated connector.
- Tip 3: Tighten the housing and cable entry properly during assembly so the seal can do its job; a loose assembly lets water and dust in.
- Tip 4: Keep the connection off the ground and out of puddles, since IP44 protects against splashes but not against standing water or submersion.
- Tip 5: Do not pressure-wash or hose down the connector, and dry it before connecting if it has been splashed.
- Tip 6: Inspect before every use for cracks, discolouration, burn marks, or loose contacts, and take any damaged unit out of service.
- Tip 7: Plug in fully and make sure the connection is firm; a half-seated plug can arc and overheat at the contacts.
Applications
Construction & Temporary Site Power
- Connecting temporary distribution boards and extension leads on site
- Powering tools and lighting in damp or dusty work areas
- Linking site cabins and welfare units to temporary supply
- Powering pumps and equipment under cover but exposed to splashes
- General outdoor power connections in building works
Workshops, Factories & Warehouses
- Fixed or semi-fixed connections for machinery and equipment
- Power connections in damp or dusty production areas
- Wiring wash-bay and yard equipment where splashes are likely
- Replacing worn domestic plugs on heavy-use equipment leads
- General-purpose industrial power connections
Events, Exhibitions & Outdoor Use
- Power connections for stages, lighting, and sound equipment
- Temporary power at outdoor markets, roadshows, and exhibitions
- Powering food stalls and kiosks in covered outdoor areas
- Connections for generators feeding temporary distribution
- General outdoor event power, kept off the ground and out of standing water
Features & Benefits Table
| Feature | Benefit |
| 16A rated, 220–250V | Handles typical single-phase equipment and tool loads up to the rated current |
| IP44 protection | Protects against dust and splashing water from any direction in damp or outdoor areas |
| 5.00mm brass contact columns | Brass conducts well and resists corrosion for firm, reliable contact |
| Flame-retardant engineering plastic shell | Tough housing that is designed to resist spreading a flame |
| Socket and plug supplied as a matched set | No need to source mating parts separately |
| Compact 125 x 50 x 50mm size | Easy to fit into leads, boards, and equipment connections |
| Blue and white colouring | Clear industrial look that helps crews recognise the connection type |
Frequently Asked Questions (FAQ)
Q1. What is this plug and socket used for?
It is an industrial 16A, 3-pin connector for 220-250V supply, used for site power, workshops, outdoor setups, and events where a tougher, splash-protected connection is needed.
Q2. What does IP44 mean?
IP44 means the connector is protected against solid objects larger than 1mm and against water splashing from any direction. It is not rated for submersion, pressure washing, or water jets.
Q3. Is it fully waterproof?
No. It is splash-protected to IP44. Keep it off the ground and out of standing water, and do not hose it down.
Q4. What is in the box?
Each set includes 1 industrial waterproof socket and 1 industrial waterproof plug.
Q5. What material are the contacts and shell made from?
The contacts are 5.00mm brass columns and the shell is a high-strength flame-retardant engineering material.
Q6. What size is it?
About 125 x 50 x 50mm (4.9 x 2 x 2 inches). The weight of one set is about 0.2 to 0.4 kg.
Q7. Is it certified or approved?
No certification or approval is stated for this product. Please confirm the applicable approval status with our sales team before sale or installation.
Q8. How do I order the 16A waterproof plug and socket in Malaysia?
You can request a quotation through www.blue-box.asia or contact Blue Box Sdn Bhd’s sales team by phone or WhatsApp for fast, Malaysia-wide delivery support.
Pain Points vs. Solutions
| Pain Point | Blue Box Solution |
| Household plugs fail quickly on damp, dusty, or rough sites | IP44 industrial shell protects against dust and splashing water |
| Loose or corroded contacts cause heat and unreliable power | 5.00mm brass contact columns give firm, corrosion-resistant contact |
| Plastic housings crack or spread flame when a fault occurs | High-strength, flame-retardant engineering material shell |
| Mismatched socket and plug parts cause poor fit | Supplied as a matched socket and plug pair |
| Sourcing power connections and site supplies from different suppliers slows procurement | Available alongside Blue Box’s Warehouse Operational Supplies range |
Technical Documentation
Product Code: P03-00034
Brand: BBSB
Rated Current: 16A
Voltage: 220–250V
Poles / Cores: 3 (3 pin)
Protection Level: IP44
Contact Material: Brass, 5.00mm column
Shell Material: High-strength flame-retardant engineering material
Colour: Blue + white
Size: About 125 x 50 x 50mm / 4.9 x 2 x 2 inches
Package Contents: 1 socket + 1 plug
Item Weight: 0.2–0.4 kg per set (1 socket + 1 plug)
Est. Packed Box Size (Courier): Approx. 15cm (L) x 12cm (W) x 7cm (H) — estimated, based on two 125 x 50 x 50mm pieces side by side plus packing allowance
Reference Standard: None stated for this product; refer to DOSH Malaysia (www.dosh.gov.my) and Suruhanjaya Tenaga (www.st.gov.my) for workplace electrical safety and equipment approval requirements
Notes to confirm: (1) The size of about 125 x 50 x 50mm was assumed to be per piece; confirm whether it describes the socket, the plug, or the pair. (2) The product text included the word “Van” (“Plug Van 16 Amp”), which was left out as it looked like a stray word; confirm if the set is meant for a specific use, such as vehicles. (3) The packed box size is an estimate, since none was provided. (4) No certification or approval was stated; confirm status before listing.
